PEM Hydrogen Generator
Time：2023-10-23 9:0:58 Hits：
Introduction:
HX-1800C/3000C are equipped world advanced SPE technology ( solid polymer electrolyte), also called PEM( Proton Exchange Membrane). Through electrolysis of pure water, it produces high purity hydrogen reaching upwards of 99.99%. One machine is suited for several applications: Inhalation; Making hydrogen rich water; skin treatment etc...
HX-1800C/3000C are floor type with four wheels, easy move, advanced digital type machine. With supper large English digital screen,display H2 flow, using time, water level condition and H2 purity. Also have sleep mode. Touch screen, microcomputer automatically control, very easy operation.
Gas flow is adjustable at random. HX-1800C: Gas flow is from 0--1800ml/min.HX-3000C:
gas flow is 0--3000ml/min, Have timing function, can set using hour and minutes (Add or reduce time in half an hour) , have short of water alarm function. Screen brightness also can be set.
Whole machine outside is made high quality ABS plastic. Streamline design, easy to move. Due to our 30 years production experience, these durable machines will continue to produce hydrogen for 5--10 years trouble-free.
Technical Data:
Model | HX-1800C | HX-3000C |
Hydrogen Output Purity | 99.99% | 99.99% |
Oxygen Output Purity | 99.9% | 99.9% |
Gas Output Flow | Adjustable:0-1800ml/min H2 flow: 0--1200ml/min O2 flow:0--600ml/min | Adjustable:0-3000ml/min H2 flow:0--2000ml/min O2 flow:0--1000ml/min |
Time Setting | 00:30 to 24.00 hours | |
Output Pressure | About 0.2MPa | |
Water Requirement | Deinized water or redistilled water | |
Water Tank Capacity | 3 Liters | |
Pressure Stability | <0.001mpa< span=""> | |
Power Supply | 220V±10% or 110V±10% 50Hz--60Hz | |
Power consumption | 500W | 800W |
Dimension | 56*38*60cm | |
Net Weight | 16kgs | 25kgs |
